CC-692 (11-Brush)
Tunnel Car Wash Equipment
The car wash tunnel system features 11 car brushes (CC-692), and it is 11.6 m long to ensure it can clean the entire car, including the car wheel guide devices.
Request a Quote
The car wash tunnel system features 11 car brushes (CC-692), and it is 11.6 m long to ensure it can clean the entire car, including the car wheel guide devices.
| Tunnel car wash machine CC-692 | |
| Overall dimension | 13200*3800*3440mm |
| Installation size | 14310*4000*3440mm |
| Voltage | AC 380V50Hz (5-wire system) |
| Water-source requirement | Pipe diameter: DN25, water flow≥200L/min |
| Air supply | Air pressure: 0.75-0.9MPa, air flow≥0.1m³/min |
| Ground flatness | Deviation≤10mm |
| Available car to wash | Car\jeep\coach within 10 seats |
| Moving range | 5300*2100*2100mm (wheelbase≤3200mm) |
| Car wash capacity | 45-55 sets/hour |
| Water consumption | 155L/car |
| Power consumption | 0.6kW/car |
| Shampoo consumption | 20-40ml/car |
| Wax consumption | 30ml/car |
| PLC | Mitsubishi from Japan |
| Optoelectronic monitoring | Banner from the USA |
| Brush rotating motor | SITI |
| Contactor | Schneider from France |
| Proximity Switch | PEPPERL FUCHS from Germany |
| Small brush cylinder | AirTAC |
| Wax suction pump | Bello Zon from Germany |
| Hot-dipped galvanized frame | 1 group |
| Shampoo spray system | 1 group |
| Wax spray system | 1 group |
| Contour-following drying system | 1 group |
| Car entry guide rail apparatus | 1 group |
| Chassis spraying system | Can be added |
| High pressure water spraying device | Can be added |
| Equipment data intellectualization | Management, spot check, operation |
| Self-diagnose system | Automatic fault display, self-checking |
| Short vertical brushes | 4 |
| Lifting top brush | 1 |
| Fixed long vertical brushes | 2 |
| Moving long vertical brushes | 2 |
| Horizontal tire brushing system | 2 |
Get in touch to learn more about our advanced car wash systems, designed to deliver efficient, reliable, and customized cleaning solutions for vehicles of all types.
We will provide training and guidance to help you do good pre-sales & after-sales service;
Let's work together to get win-win result!
