Rollover Car Wash Machine CF-320 (Without Dryer)

This product has been discontinued and removed from our shelves.

Our car wash system without dryer (CF-320) is a price favorable car wash machine, featuring a microcontroller unit (MCU) and higher security. The corrosion resistance of the galvanized frame of the vehicle washing equipment is 10-20 times that of hot galvanized plate, increasing its service life. To simplify operations and improve the washing efficiency, we utilize a Two-Click washing method. The following is basic information about this car wash system without dryer.

Parameters
Model CF-320
Dimension L*W*H :2.4m×3.6m×2.9m
Rail length: 9m rail distance:3.2m
Assembling Range L*W*H :10.5m×3.7m×3.1m
Moving Range L*W: 10000mm×3700mm
Voltage Voltage AC380V 50Hz Capacitance 20KVA
Water Supply DN25mm water flow rate≥80L/min
Air Pressure 0.75～0.9Mpa air flow rate≥0.1m3/min
Ground Flatness Deviation≤10mm
Applicable Vehicles Sedan/jeep/minibus within 10 seats
Applicable Car Dimension L*W*H: 5.4m×2.1m×2.1m
Washing Time 1 rollover 2ˊ05〞/2 rollover 3ˊ55〞
Advantages
  • Fully automatic: microcontroller unit (MCU) ensures high efficiency and low failure rate, and allows for remote upgrading.
  • The corrosion resistance of the galvanized frame of the vehicle washing equipment is 10-20 times greater than that of hot galvanized plate, increasing service life.
  • Two-Click washing method simplifies operations.
  • Built-in self-diagnose system can recognize and remove obstacles.
  • Full-direction cleaning is achievable.
Configurations
Standard Devices Optional Devices
Shampoo spray system Undercarriage wash system
Equipment data intellectualization Water wax spray system
Self-diagnose system Contour following drying system
Brush system
